OrderDeleteBatchDealDeleteBatchPositionDeleteBatchMT5AccountMarginCallEventArgs StreamMarginCallUpdates(TradePlatformId) method to MT5 hub to monitor MC/SO events. Every time something happen on server, you will receive structure which JS object has self-explanatory example below: account: {
"login": 2009,
"currencyDigits": 2,
"balance": 3025.7,
"credit": 0,
"margin": 3279.67,
"marginFree": 6.03,
"marginLevel": 100.18385996152051,
"marginLeverage": 100,
"profit": 386,
"storage": 0,
"floating": 386,
"equity": 3285.7,
"soActivation": "None",
"soTime": null,
"soLevel": 0,
"soEquity": 0,
"soMargin": 0,
"blockedCommission": -126,
"blockedProfit": -185428,
"marginInitial": 0,
"marginMaintenance": 0,
"assets": 0,
"liabilities": 0
}
type: "MarginCall"
direction: "Leave"
Direction can be Enter or Leave, Type can be MarginCall or StopOut.
rights enumerable, added missing values, so JSON parser will be ok;HistoryRequestByGroupHistoryRequestByTicketsOrderRequestByTicketsDealRequestByTicketsActivationFlags field type switched from uint to TradeActivationFlags type;DealRequestByGroupDealRequestByGroupSymbolOrderGetByGroupOrderGetBySymbolOrderRequestByGroupOrderRequestByGroupSymbolPositionGetByGroupPositionGetBySymbolSymbolUpdate added to MT5 controller;AggregationType;OrderFilling enum BoC added, FOK and IOC renamed to FoK and IoC;OrderTime GTC -> GtC;OrderActivation Stoplimit -> StopLimit, Stopout -> StopOut;UsersRights Technical and ExcludeReports enums added;Retcode replaced with RetCode where applicable;DealUpdate method to MT5 controller;SubscribeToTicks, SubscribeToAllTicks, UnsubscribeFromAllTicks.UserGetByLoginsPositionGetByTicketsGroupGetGroupRequestGroupRequestArrayOrderGetOrderGetByTicketsOrderGetByLoginsDealRequestByTicketsDealRequestByLoginsDealRequestByTicketChartRequestSymbolGet01.01.1970 - null will be returned, where date time is nullable field;SymbolRequestArraySubscribeToSymbols
OnSymbol and OnSymbolSync callbacks;UnsubscribeFromSymbolsSubscribeToTicks, SubscribeToAllTicks
OnTick callback;UnsubscribeFromAllTicksSubscribeToPositionsSubscribeToOrdersUserAdd: If any of passwords (Password or PasswordInvestor) is null or empty, both of them will be generated.
We will generate passwords and call manager api method to create user.
If MT5 does not like our password, we will try again with a new pair, a maximum of 10 times;ManagerCurrent returns updated structure signature;PositionGetByLoginsSMTTime in favor of default .NET DateTime to/from UnixTime/FILETIME converter;SubscribeToUsers, updates will be sent through callback(-s):
OnUserUnsubscribeFromUsersSubscribeToDeals, updates will be sent through callback(-s):
OnDealOnDealCleanUnsubscribeFromDealsUserDeleteClientDeleteUserGetByGroupTimeGetManagerCurrentUserAccountRequestDealerSend response signature changed;UserAccountGet method to MT5 controller;UserUpdate now POST method;MT5Client requires PersonName;MT5 controller: added TimeServer method;UserUpdate, UserPasswordCheck and UserPasswordChange MT5 methods.ServerTime method to MT4 endpoint;Connect method supports ConnectArgs structure where you can specify TimeoutMs, in milliseconds (30 seconds by default). You shall start your duties from this method;SetTicksAggregationSettings - not yet available;SubscribeToAllMarginUpdates - not yet available;UnsubscribeFromAllMarginUpdates - not yet available;UnsubscribeFromMarginUpdates - not yet available;SubscribeToMarginUpdates - not yet available;StreamMarginDiff - not yet available;Ping removed, use Connect instead;All methods awaits structure and send structures.
Because of guide
Old code:
connection.invoke("SubscribeToTicks", tradePlatform, "EURUSD")
New code:
connection.invoke("SubscribeToTicks", {tradePlatform, symbol: "EURUSD"})
All callbacks now return structures.
Old code:
connection.on("onTick", function (tradePlatform, tick) {
/* your code here */
});
New code:
connection.on("onTick", function (args) {
const {tradePlatform, tick} = args;
/* your code here */
});
Check CPlugin.WebAPI.Realtime.ts for further details.
StreamTrades sent updates for all platforms, regardless of chosen one;StreamUserUpdates sent updates for all platforms, regardless of chosen one;RefreshAPI method removed from /TradePlatforms controller.TradesGetByLogin method to MT4 RESTfulStreamUserUpdates returns UserUpdate structure which ispublic class UserUpdate
{
public TransactionType Type;
public UserRecord User;
}
StreamMarginDiff to MT4 hub;StreamUserUpdates to MT4 hub;{
"errorType": "MT4API",
"errorCode": "NotEnoughRights",
"errorDescription": "Not enough rights",
"requestId": "unique id"
}
JournalRequest, TradeRecordsRequest, TradesUserHistory, CfgRequestSymbol, AdmBalanceCheck functions will not throw exception but will return BadRequest if manager account does not have enough rights;IAsyncEnumerable<TradeExEventPayload> StreamTrades(Guid tradePlatform)bool Connect(Guid tradePlatform)OnMT4ConnectionStatus will only be run once status changed, and never during connect to hub;Connect method removed from MT4 hub;KeepConnectionAliveDuring parameter;DealerBalance MT5 methodClientRequest MT5 methodUserRequest MT5 methodTick structure got LastTime fieldStreamMarginCallUpdates method to stream margin call updates. During subscription you get all accounts in M/C state. Then, only updates will be send (mc->normal and
normal->mc). Code example is hereStreamAllTicks method to the MT4 hub, read more hereCfgRequestSymbolGroup, more info hereClientAddHistoryRequest, DealRequest return customized enumsDealerSend call now use customized enums, so call with
parameters {"Login":2000, "Action": "TA_DEALER_POS_EXECUTE", "Symbol":"EURUSD", "Volume":100, "Type": "OP_BUY", "PriceOrder": 1.01} will not work, please convert arguments to
the new format {"Login":2000, "Action": "DealerPosExecute", "Symbol":"EURUSD", "Volume":100, "Type": "Buy", "PriceOrder": 1.01}UserAdd methodDealRequest MT5 methodHistoryRequest to MT5 controllerTestController::TryParseDateTime to test .NET DateTime parser values validity;/healthz URL endpoint to tell the status, possible values are (HTTP Code, string): [{200,Healthy}, {200,Degraded}, {503,Unhealthy}];UserRecordsRequest method;api-version passed within query string not supported anymore, to specify api version. Use URL path instead;v2 api endpoint;SignalR::MT4 hub now have method SetTicksAggregationSettings. Take a look to demo page source code to get example of
use.OnlineExChanges (OnlineEx were used before), which is now distinct against changes.void SubscribeToOnlineUpdates(Guid tradePlatform), void UnsubscribeFromOnlineUpdates(Guid tradePlatform) to MT4 hub and
corresponding OnOnlineUpdate(Guid tpConnectionKey, TransactionType transactionType, int login) callback.UserRecordsRequest and UsersRequest methods to MT4 controllercacheId of Guid type,cacheTimeout specifying timout in seconds./API/MT4/{mt4id}/JournalRequest/2020-08-01/2020-09-20/Full?cacheId=63cb3a5f-1bd6-445d-8da8-1b3d8a6ce70d&cacheTimeout=60cacheId specified, it will search in DB for cached record associated for this ID, if found - will return cached data instead.cacheTimeout seconds record will be deleted from DB permanently and will not be available.OnMarginUpdate Hub method returned zero balanceUnsubscribeFromMarginUpdates to MT4HubMT4::JournalRequestMT4Hub called OnMarginUpdate callback with empty list even client did not subscribe for itHubs:MT4 margin level will be sent for all subscribed users, if subscribed explicitly, does not matter if there any open positions. Or if subscribed to all data, it will send
for those accounts who have open positions.MT4::ManagerCommon and MT4::ManagerCommonEx methodsMT4::AdmBalanceCheck login to be specified as of AdmBalanceCheck/<login>MT4::AdmBalanceCheck always return value of type AdmBalanceCheck (in comparison to ManagerAPI which does not return anything, if balance is ok)MT4::AdmBalanceCheck now supports only single login specified within URI AdmBalanceCheck/{login:int:min(1)}MT4::AdmBalanceFix now supports only single login specified within URI AdmBalanceCheck/{login:int:min(1)}MT4::UserRecordNew call result, passwords were suffixed with \0 charactersMT4::UserPasswordSet now requires Update permission, instead of RequestMT4::UserRecordNew API method accept and return structure of type UserRecordNew where password and password investor presented in plain text, and only once. Following
requests of user settings will return both passwords stored in base64MT4::AdmTradeRecordModify methodMT4::AdmBalanceCheck and MT4::AdmBalanceFix methodsGET method for MT4 MarginLevelRequest which does not require pumping and does not need open trades to return a result (in comparison to MarginLevelGet)SymbolAdd. Then during whole WebAPI runtime it will collect prices for you into internal buffer. Keep in mind, this is not a history, only most
recent prices for each explicitely monitored symbol. By default, symbol will be in market watch when there are open trades on it. Otherwise, you will not see prices until add
symbol to watch list.TickInfoLast/{symbol} - request prices for specified symbol onlyTickInfoLast - request prices for all monitored symbolsGET MT4/<id>/TickInfoLastGET MT4/<id>/TicksRequestGET MT4/<id>/ChartRequestPOST API/MT4/<id>/CfgUpdateGroupPOST API/MT4/<id>/UserRecordUpdate/odata/[controller]({id}) should be redirected to `/api/[controller]/{?id}POST /odata/TradePlatforms({Id})/NS.MT5DealerSend to send trade request to MT5 server
